SIMMG2360TS
Availability: In Stock
RoboG4® AC Induction Motor Drive, Single Channel, 1 × 40 A continuous, 1 × 60 A (30 s), 1 × 90 A peak (2 s), 60 V, Encoder inputs, USB, CAN, 14 Dig/Ana IO, Molex Connectors, Cooling plate with ABS cover, STO PLe, Cat3, SIL3.
$715.00
Status :
Active
Documentation
| # | Name | Version | Size |
|---|---|---|---|
| 1 |  SIMMG23xx datasheet | v 1.1, Feb 11, 2026 | 1.02 MB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | Roboteq Controllers User Manual v3.2 | v3.2 December 16, 2025 | 13.5 MB |
Files
| # | Name | Version | Size |
|---|---|---|---|
| 1 |  Roborun+ PC Utility v3.3 | v3.3 February 2, 2026 | 62.95 MB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | SIMMG2XXXS Firmware Update v3.2c | v.3.2c, April 2, 2026 | 318.19 KB |
| # | Name | Version | Size |
|---|---|---|---|
| 1 | SBLM2x-step3d | 2.87 MB |
Family
Motor Type
AC Induction
Power
Max Voltage
60
Design Generation
Gen4
Number of Channels
1
Max Amps per Channel
90 (2 sec)
Continuous Amps per Channel
40
Power Connections
Molex
Communication
RS232
Yes
RS485
Yes
USB
Yes
Ethernet
No
Rotor Sensor
Encoder
Yes
Input/Outputs
Max Analog Inputs
8
Max Digital Inputs
10
Max Digital Outputs
4
Max Pulse Inputs
8
Functional Safety
Safe Torque Off (STO)
Yes
Mechanical
Cooling
Conduction plate
Dimensions
(123mm x 83 m x 25mm)
Weight
215g
